Gas Solenoid Valve – Class A, EN 161, IP65, 500 mbar Max

The HONEYWELL KROMSCHRODER VAS1-/15R/LW is a Class A solenoid valve intended for use in automatic shut-off applications for gas and air, meeting EN 161 standards. The valve is configured to be closed when not energized and features a pilot lamp and flow adjustment. It is suitable for use with maximum operating pressures up to 500 mbar and offers protection rated at IP65. The product holds EU certification as well as FM and CSA approvals, compatible with systems requiring SIL 3 or PL e compliance.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Opening/closing types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicator, visual indicator, fitted bypass/pilot gas valve, or pressure switches
