Gas Solenoid Valve - Class A, IP65, 500 mbar, DN10-125

The HONEYWELL KROMSCHRODER VAS1-/NW is a solenoid valve intended for use in the control of gas and air line flow. Classified as a Class A valve according to EN 161, it operates in a normally closed position when de-energized and is rated for operation at pressures up to 500 mbar. The unit provided with an IP65-rated enclosure, equipped with a pilot lamp and adjustable flow mechanism, and certified under applicable EU, FM, and CSA standards. It is suitable for installation in systems requiring compliance with SIL 3 or PL e.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection types: threaded or flanged
• Operation options: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicators, visual indicators, fitted bypass/pilot gas valves, or integrated pressure switches
