Gas Solenoid Valve - NC, 500 mbar, IP65, EN 161 Certified

The HONEYWELL KROMSCHRODER VAS125R/LWSR is a Class A solenoid valve intended for use in applications requiring the control of gas and air flow. This valve is normally closed (NC) and requires energization to open, operating at a maximum pressure of 500 mbar. It features a pilot lamp, flow adjustment, and an IP65-rated enclosure. The unit meets EN 161 standards and holds EU certification as well as FM and CSA approvals. It is certified according to SIL 3 and PL e standards.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Opening/closing types: quick opening with quick closing or slow opening with quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicator, visual indicator, fitted bypass/pilot gas valve, or integrated pressure switches
