Gas Solenoid Valve - NC, 500 mbar, IP65, EN 161 Class A

The HONEYWELL KROMSCHRODER VAS115/-R/NQSR is a Class A solenoid valve intended for use in applications requiring the shut-off of gas and air. This valve conforms to EN 161 standards, is normally closed (NC) when not energized, and supports a maximum operating pressure of 500 mbar. It includes pilot lamp indication and flow adjustment options. The unit is rated to IP65 for ingress protection and holds certification meeting requirements up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicator, visual indicator, fitted bypass/pilot gas valves, or integrated pressure switches
