Gas Solenoid Valve - NC, Class A, EN 161, IP65, SIL 3

The HONEYWELL KROMSCHRODER VCS8100F05NLWR3B/PMMP/MPPM is a Class A solenoid valve in accordance with EN 161 standards. It is intended for use in automatic shut-off applications for gas and air. The valve is normally closed (NC) type; closes when not energized and features a pilot lamp and flow adjustment capabilities. It is certified for use in systems up to SIL 3 and PL e, with approvals from FM and CSA, as well as EU certification. The protection rating: IP65.

Key features include:

• Maximum operating pressure: 500 mbar
• Available sizes: 1 to 9; nominal diameters (DN): 10 to 125
• Connection types: threaded or flanged
• Operation modes: quick opening/quick closing or slow opening/quick closing
• Mains voltage options: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Versions available with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches
