Gas Solenoid Valve - Shut-Off, EN 161, IP65, DN10-125

The HONEYWELL KROMSCHRODER VAS1-0/NK is a solenoid valve intended for use as a shut-off valve for gas and air in industrial systems. This Class A valve meets EN 161 standards and is configured to be closed when not energized. It features a pilot lamp, flow adjustment, and an IP65 rating for ingress protection. The unit holds certifications from relevant authorities, including compliance with EN 161, FM, CSA, SIL 3, and PL e standards.

Key features include:

• Size range: 1 to 9; nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Maximum operating pressure: 500 mbar
• Mains voltage options: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicators, visual indicators, fitted bypass/pilot gas valves, or integrated pressure switches
