Gas Solenoid Valve - VAS Series, 500 mbar, Class A, IP65

The HONEYWELL KROMSCHRODER VAS780F05LWGRB/PP/PP is a Class A solenoid valve intended for use in applications requiring automatic shut-off of gas and air. This unit is rated to meet EN 161 standards and is normally closed (de-energized state). It has a maximum rated operating pressure of 500 mbar and includes pilot lamp indication and flow adjustment options. The valve carries EU certification as well as FM and CSA approvals, and it holds certification meeting requirements for SIL 3 and PL e.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Protection rating: IP65
• Available versions include models with position indicators, visual indicators, fitted bypass/pilot gas valves, or integrated pressure switches
