Gas Solenoid Valve - VAS-VCS, Auto Shut-Off, 500 mbar, IP65, EN 161

The HONEYWELL KROMSCHRODER VAS780F05LWSR3B/MM/PP is a Class A solenoid valve rated for automatic shut-off of gas and air per EN 161 standards. This valve remains closed when de-energized and has a maximum operating pressure rating of 500 mbar. It features a pilot lamp, flow adjustment capability, and an IP65-rated enclosure. The unit holds EU certification as well as FM and CSA approvals, and it is certified for use in systems up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches DG../VC
