Gas Solenoid Valve – VAS-VCS, NC, 500 mbar, Threaded/Flanged, EN 161

The HONEYWELL KROMSCHRODER VLV,SOLND,SZ 3,NPT,VAS3T /LWSR,SLOW OPN is a solenoid valve intended for use in applications requiring the control of gas and air flow. This Class A valve is manufactured in compliance with EN 161 standards and is normally closed (NC) type; closes when not energized, and is rated for maximum operating pressure of 500 mbar. It includes selectable opening/closing speed options, as well as integrated pilot lamp and flow adjustment options.

Key features include:

• Size: Available in sizes from 1 to 9 (DN 10 to DN 125)
• Connection type: Threaded or flanged
• Opening/closing action: Quick opening/quick closing or slow opening/quick closing
• Maximum pressure: Up to 500 mbar
• Voltage options: Compatible with mains voltages of 24 V DC, 120 V AC, or 230 V AC
• Electrical connection: Terminal style
• Certifications: EU certified; FM and CSA approved; rated for systems up to SIL 3 and PL e
• Additional versions available with position indicators, bypass/pilot gas valves, or fitted pressure switches
