Gas Solenoid Valve - VAS1, Class A, 500 mbar, IP65, EN 161 Certified

The HONEYWELL KROMSCHRODER VAS1-/10R/LPGR is a Class A solenoid valve intended for use in applications requiring the shut-off of gas and air. This valve manufactured to meet EN 161 standards, configured to remain closed when not energized, and rated for a maximum operating pressure of 500 mbar. It includes pilot lamp and adjustable flow settings, with an ingress protection rating of IP65. The unit is EU certified as well as FM and CSA approved, and it is compatible with systems rated up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9
• Nominal diameter (DN): 10 to 125
• Connection types: Thread or flange
• Operation: Quick opening/quick closing or slow opening/quick closing options available
• Mains voltage options: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicator, visual indicator, fitted bypass or pilot gas valve, and fitted pressure switches DG../VC
