Gas Solenoid Valve - VAS110, 500 mbar, IP65, EN 161
Mfr # KS88032780
Zoro # G615422812
Specifications
Product Information
Description
The HONEYWELL KROMSCHRODER VAS110/-R/NP is a Class A solenoid valve intended for use in applications requiring the control of gas and air flow, as specified by EN 161 standards. The valve is configured to be in a closed position when not energized, according to manufacturer specifications, and features a pilot lamp and flow adjustment. It operates at a maximum pressure of 500 mbar, rated IP65 according to IEC standard 60529, and is certified under applicable EU directives and approved by FM and CSA per their respective standards. The product is certified for integration into systems with requirements up to SIL 3 (per IEC 61508) and PL e (per ISO 13849-1), subject to correct installation, operation, and maintenance.
Key features include:
- Size range: 1 to 9; DN (nominal diameter): 10 to 125
- Connection options: threaded or flanged
- Operation modes: quick opening/quick closing or slow opening/quick closing
- Mains voltage options: 24 V DC, 120 V AC, or 230 V AC
- Electrical connection via terminal block
- Available with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches DG../VC
Restrictions
