Gas Solenoid Valve - VAS2T25, 500 mbar, IP65, Auto Shut-Off, Class A

The HONEYWELL KROMSCHRODER VAS2T25/-N/LQSR is a Class A solenoid valve intended for use in applications requiring automatic shut-off of gas and air, conforming to EN 161 standards. The valve is configured to be in a closed position when not energized and is rated for a maximum operating pressure of 500 mbar. It features a pilot lamp and flow adjustment, with an ingress protection rating of IP65. The unit holds EU certification as well as FM and CSA approvals, and it is certified for use in systems up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Compatible with mains voltages of 24 V DC, 120 V AC, or 230 V AC
• Electrical connection provided by terminal block
• Available versions include models equipped with position indicator, visual indicator, bypass or pilot gas valve fittings, and pressure switches DG../VC
