Pressure Switch - Adjustable Air/Flue Gas, DL 24KT 3

The HONEYWELL KROMSCHRODER SW,PRESS,AIR,DL 24KT 3 is an A/C pressure switch rated for use in applications involving air and flue gas pressure measurement. It is compatible with positive, negative, and differential pressures within the specified ranges in air, flue gas, or non-aggressive gases. The switching point is adjustable using a setting dial within the specified range.

Key features include:

• Adjustable switching range from -1.5 to 150 mbar (0.12 to 20"WC)
• Tube connections: CE versions (Rp 1/4, Rp 1/8), UL versions (1/4" NPT, 1/8" NPT)
• Contact options: Silver or gold contacts with voltage and current ratings specified for CE and UL versions
• Electrical connection through screw terminals with M16x1.5 cable gland or 1/2" NPT conduit; includes a 4-pin plug and socket
• Certified by EU, UL listed, FM approved, AGA approved; RoHS compliant
• Silicon-free construction
