Pressure Switch - Air/Flue Gas, Adjustable, DL 40KTG 3

The HONEYWELL KROMSCHRODER SW,PRESS,AIR,DL 40KTG 3 is an A/C pressure switch rated for use in applications involving air and flue gas pressure measurement. It is compatible with positive, negative, and differential pressures within the specified range when used with air, flue gas, or non-aggressive gases. The switching point is adjustable via a setting dial within the product’s specified operating parameters.

Key features include:

• Pressure range: -1.5 to 150 mbar (0.12 to 20"WC)
• Pneumatic connections: CE versions with Rp 1/4 and Rp 1/8; UL versions with 1/4" NPT and 1/8" NPT
• Contact options: Silver contacts (24–250V AC, 0.05–5A) or gold contacts (5–250V AC, 0.01–5A) for CE; silver contacts (30–240V AC, 5A) or gold contacts (max 30V AC, 0.05A) for UL
• Electrical connection via screw terminals with M16x1.5 cable gland or 1/2" NPT conduit
• Includes a four-pin plug and socket; silicon free construction
• Certified by EU authorities and listed by UL, FM, AGA
