Pressure Switch for Air/Flue Gas, -1.5–150 mbar, Adjustable

The HONEYWELL KROMSCHRODER SW,PRESS,AIR,DL 150AG 32 is an A/C pressure switch rated for use in applications involving air and flue gas pressure measurement. It is compatible with detection of positive, negative, and differential pressures within the specified ranges when used with air, flue gas, or other non-aggressive gases. The switching point is adjustable via a setting dial within the product’s specified range.

Key features include:

• Pressure range: -1.5 to 150 mbar (0.12 to 20"WC)
• Pneumatic connections: CE versions with Rp 1/4 and Rp 1/8; UL versions with 1/4" NPT and 1/8" NPT
• Contact options: Silver contacts (24–250V AC, 0.05–5A) or gold contacts (5–250V AC, 0.01–5A) for CE; silver contacts (30–240V AC, 5A) or gold contacts (max 30V AC, 0.05A) for UL
• Electrical connection: Screw terminals with M16x1.5 cable gland or screw terminals with a 1/2" NPT conduit; includes a four-pin plug and socket
• Certifications: EU certified, UL listed, FM approved, AGA approved
• Silicon-free construction
