Pressure Switch for Air/Flue Gas, Adjustable, -1.5–150 mbar

The HONEYWELL KROMSCHRODER SW,PRESS,AIR,DL 10K 5 is an A/C pressure switch rated for use in applications involving air and flue gas pressure measurement. It supports positive, negative, and differential pressure measurements in air, flue gas, or other non-aggressive gases. The device features a switching point adjustment via a setting dial and is compatible with specified pneumatic connection types.

Key features include:

• Pressure range: -1.5 to 150 mbar (0.12 to 20"WC)
• Adjustable switching point using a setting dial
• Tube connections; CE versions: Rp 1/4, Rp 1/8; UL versions: 1/4" NPT, 1/8" NPT
• Contact options: Silver contacts (24–250V AC, 0.05–5A), Gold contacts (5–250V AC, 0.01–5A) for CE; Silver contacts (30–240V AC, 5A), Gold contacts (max 30V AC, 0.05A) for UL
• Screw terminals with M16x1.5 cable gland or optional screw terminals with a 1/2" NPT conduit
• Certified to applicable standards, including EU, UL, FM, AGA, EAC, and RoHS compliance
• Silicon-free construction
