Pressure Switch for Air/Flue Gas, Adjustable, DL..E Series

The HONEYWELL KROMSCHRODER SW,PRESS,AIR,DL 14E 1 is an A/C pressure switch rated for use in applications involving air and flue gas pressure detection. It is compatible with systems utilizing air, flue gas, or non-aggressive gases within the specified pressure ranges. The switching point can be adjusted via an integrated adjustment screw to meet specific system requirements.

Key features include:

• Pressure range: 30 to 3500 Pa (0.12 to 14.1" WC) for DL2,4,14,35E models
• Adjustable switching point with adjustment screw
• Tube connections for pneumatic interface
• Electrical contacts: Silver (24–250V AC, 0.05–5A), Gold (5–250V AC, 0.01–5A) CE version; Gold (max 30V AC/0.05A), Silver (30–240V AC/5A) UL versions
• Electrical connection via 6.3x0.8 AMP connectors
• Certified by EU authorities and listed by UR and FM; also AGA approved and RoHS compliant
• Silicon-free construction
