Solenoid Gas Safety Valve - 500 mbar, IP65, Class A

The HONEYWELL KROMSCHRODER VAS3T40/-N/NKGR is a Class A solenoid gas safety valve. It is intended for use as an automatic shut-off component in gas and air systems. It operates with a closed position when de-energized and is rated for a maximum operating pressure of 500 mbar. The unit features an integrated pilot lamp, flow adjustment capability, and an IP65 enclosure rating. It holds EU certification as well as FM and CSA approvals.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches DG../VC
