Solenoid Gas Safety Valve - 500 mbar, IP65, Class A

The HONEYWELL KROMSCHRODER VAS1-/25R/NWGL is a Class A solenoid gas safety valve intended for use as an automatic shut-off component in gas and air systems. It operates closed when de-energized and is rated for a maximum operating pressure of 500 mbar. The unit features a pilot lamp, flow adjustment, and an IP65-rated enclosure. It holds EU certification as well as FM and CSA approvals, with certification according to SIL 3 and PL e standards.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation modes: quick opening/quick closing or slow opening/quick closing
• Mains voltage options: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches
