Solenoid Gas Safety Valve – 500 mbar, IP65, SIL 3 Certified

The HONEYWELL KROMSCHRODER VAS125/-R/NW is a Class A solenoid gas safety valve intended for use as an automatic shut-off component in gas and air systems. The valve remains closed when de-energized and is rated for a maximum operating pressure of 500 mbar. It features a pilot lamp, flow adjustment capability, and an IP65-rated enclosure. This model is certified according to EU standards as well as FM and CSA approvals, with certification according to SIL 3 and PL e standards.

Key features include:

• Valve sizes from 1 to 9; nominal diameters (DN) from 10 to 125
• Connection options: threaded or flanged
• Quick opening/closing or slow opening/quick closing operation modes
• Available mains voltages: 24 V DC, 120 V AC, or 230 V AC
• Terminal electrical connection
• Optional versions include position indicator with visual display, fitted bypass or pilot gas valves, and integrated pressure switches
