Solenoid Gas Safety Valve – 500 mbar, IP65, SIL 3/PL e Certified

The HONEYWELL KROMSCHRODER VCS9125F05NNARE/PPEP/PPPP is a Class A solenoid gas safety valve intended for use as an automatic shut-off component in gas and air systems. This valve operates with a maximum pressure of 500 mbar and is configured to be closed when de-energized. It features an integrated pilot lamp, flow adjustment capability, and is rated to IP65 ingress protection standards. The unit holds certification for application within SIL 3 and PL e system requirements, as well as EU certification, FM, and CSA approvals.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation modes: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicators (visual), fitted bypass/pilot gas valves, or fitted pressure switches
