Solenoid Gas Safety Valve – Class A, 500 mbar, DN10-125

The HONEYWELL KROMSCHRODER VAS2T50/-N/NQSR is a Class A solenoid gas safety valve intended for use as an automatic shut-off component in gas and air systems. This valve remains closed when de-energized and features a pilot lamp and flow adjustment. It operates at a maximum pressure of 500 mbar, holds EU certification as well as FM and CSA approvals. The unit is certified according to SIL 3 and PL e standards.

Key features include:

• Size range: 1 to 9; nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage options: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches DG../VC
