Solenoid Gas Safety Valve - Class A, 500 mbar, IP65, EN 161

The HONEYWELL KROMSCHRODER VAS365/-R/NW is a Class A solenoid gas safety valve intended for use as a solenoid valve with automatic shut-off functionality in gas and air systems. It operates in accordance with EN 161 standards, remaining closed when de-energized, and supports a maximum operating pressure of 500 mbar. The unit features a pilot lamp and flow adjustment capabilities, an IP65-rated enclosure, providing resistance to dust and water ingress per IEC standard 60529, and holds EU certification as well as FM and CSA approvals; see documentation for details on scope of certifications. It is certified according to SIL 3 (IEC/EN 61508) and PL e (EN ISO 13849-1) standards; refer to certification documents for application limitations.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Opening/closing action: available with quick-opening/quick-closing or slow-opening/quick-closing actuation options
• Mains voltage compatibility: compatible with mains voltages of either 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with visual position indicators, optional bypass/pilot gas valves, or integrated DG../VC series pressure switches
