Solenoid Gas Safety Valve – Class A, 500 mbar, IP65, EN 161
Mfr # KS88203413
Zoro # G615420153
Specifications
Product Information
Description
The HONEYWELL KROMSCHRODER VAS8100F05NW3E/MM/MM is a Class A solenoid gas safety valve intended for use as an automatic shut-off component in gas and air systems. It is rated for operation in accordance with EN 161 standards, configured to remain closed when de-energized, and is compatible with maximum operating pressures up to 500 mbar. The unit includes a pilot lamp and adjustable flow settings, an IP65-rated enclosure, and holds EU certification as well as FM and CSA approvals. It is certified for use in systems up to SIL 3 and PL e.
Key features include:
- Size range: 1 to 9; DN (nominal diameter): 10 to 125
- Connection options: threaded or flanged
- Operation types: quick opening/quick closing or slow opening/quick closing
- Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
- Electrical connection via terminal block
- Available versions include models with position indicators (visual), fitted bypass/pilot gas valves, or integrated pressure switches
