Solenoid Gas Safety Valve - Class A, 500 mbar, IP65, FM/CSA

The HONEYWELL KROMSCHRODER VAS2-/40R/NWGR is a Class A solenoid gas safety valve. It is intended for use in gas and air systems with automatic shut-off functionality. The valve is configured to be closed when not energized and operates at a maximum pressure of 500 mbar. It features a pilot lamp, adjustable flow setting, and an IP65-rated enclosure. This model meets EU certification standards and holds FM and CSA approvals, with compatibility for systems rated up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9
• Nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage options: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches
