Solenoid Gas Safety Valve - Class A, 500 mbar, IP65 Rated

The HONEYWELL KROMSCHRODER VAS1-/15R/NW is a Class A solenoid gas safety valve intended for use as an automatic shut-off component in gas and air systems. The valve remains closed when de-energized and includes a pilot lamp and flow adjustment. It conforms to EN 161 standards, with a rated operation at pressures up to 500 mbar, and has obtained EU, FM, and CSA certifications. This product is suitable for applications requiring SIL 3 or PL e performance levels.

Key features include:

• Size range: 1 to 9; nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Opening/closing types: quick opening/quick closing or slow opening/quick closing
• Compatible with mains voltages of 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Protection class IP65
• Available with optional position indicator, visual indicator, integrated bypass/pilot gas valve, or integrated pressure switches
