Solenoid Gas Safety Valve - Class A, 500 mbar, IP65 Rated

The HONEYWELL KROMSCHRODER VAS125/-R/NW is a Class A solenoid gas safety valve intended for use as an automatic shut-off valve in gas and air systems. This valve rated for operation per EN 161 standards; the valve is normally closed when de-energized, and maximum operating pressure: 500 mbar. It includes integrated pilot lamp and flow adjustment, with ingress protection rating: IP65. The product holds EU certification as well as FM and CSA approvals, and it is certified up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9; nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Opening/closing types: quick opening/quick closing or slow opening/quick closing
• compatible with mains voltages of: 24 V DC, 120 V AC, or 230 V AC
• electrical connection type: terminal block
• available versions may include position indicator, visual indicator, bypass/pilot gas valve option, or pressure switches
