Solenoid Gas Safety Valve - Class A, 500 mbar, IP65 Rated

The HONEYWELL KROMSCHRODER VAS232/-R/NW is a Class A solenoid gas safety valve intended for use in applications requiring automatic shut-off of gas and air. It operates in accordance with EN 161 standards, is closed when not energized. The unit rated for a maximum operating pressure of 500 mbar and features both pilot lamp indication and flow adjustment capabilities. This model is certified to EU standards as well as FM and CSA approvals, with certification according to SIL 3 and PL e standards.

Key features include:

• Size range: 1 to 9; nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Operation: quick opening/quick closing or slow opening/quick closing variants available
• Mains voltage options: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Protection rating: IP65
• Available versions include models with position indicators, visual indicators, fitted bypass/pilot gas valves, or integrated pressure switches
