Solenoid Gas Safety Valve - Class A, 500 mbar, IP65 Rated
Mfr # KS88024867
Zoro # G315419907
Specifications
Product Information
Description
The HONEYWELL KROMSCHRODER VAS115/-R/NW is a Class A solenoid gas safety valve intended for use in gas and air systems with automatic shut-off functionality. It operates with a closed position when de-energized and supports a maximum operating pressure of 500 mbar. The unit features an integrated pilot lamp, flow adjustment capability, and provides an ingress protection rating of IP65. It holds certification meeting SIL 3 and PL e standards, as well as EU certification, FM, and CSA approvals, and is certified for use in systems up to SIL 3 and PL e.
Key features include:
- Size range: 1 to 9; nominal diameter (DN): 10 to 125
- Connection options: threaded or flanged
- Operation types: quick opening/quick closing or slow opening/quick closing
- Mains voltage options: 24 V DC, 120 V AC, or 230 V AC
- Electrical connection via terminal block
- Available versions include models with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches DG../VC
