Solenoid Gas Safety Valve, Class A, 500 mbar, IP65 Rated

The HONEYWELL KROMSCHRODER VAS3-R/NW is a Class A solenoid gas safety valve intended for use as an automatic shut-off component in gas and air systems. The valve remains closed when de-energized and is equipped with a pilot lamp and flow adjustment. It conforms to EN 161 standards, with a rated for operation at pressures up to 500 mbar, has an IP65 ingress protection rating, and is approved by FM and CSA. This product is also suitable for installation in systems requiring compliance with SIL 3 or PL e.

Key features include:

• Size range: 1 to 9
• Nominal diameter (DN): 10 to 125
• Connection types: threaded or flanged
• Operation: available with quick opening/closing or slow opening/quick closing actuation options
• Mains voltage options: compatible with mains voltages of either 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models equipped with position indicators, visual indicators, integrated bypass/pilot gas valves, or integrated pressure switches DG../VC
