Solenoid Gas Safety Valve - Class A, 500 mbar, IP65, SIL 3 Rated

The HONEYWELL KROMSCHRODER VAS7T80A05LQGRE/4P/P3 is a Class A solenoid gas safety valve intended for use in gas and air systems with automatic shut-off function. This valve remains closed when de-energized and supports a maximum operating pressure of 500 mbar. It features an integrated pilot lamp, flow adjustment capability, and has an ingress protection rating of IP65. The unit holds EU certification as well as FM and CSA approvals, with rated for applications requiring up to SIL 3 and PL e compliance.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicator, visual indicator, fitted bypass/pilot gas valves, or fitted pressure switches
