Solenoid Gas Safety Valve, Class A, 500 mbar Max Pressure

The HONEYWELL KROMSCHRODER VAS240/-R/LPSR is a Class A solenoid gas safety valve intended for use as an automatic shut-off component in gas and air systems. The valve remains closed when de-energized and is rated for operation up to a maximum pressure of 500 mbar. It includes pilot lamp, flow adjustment capability, and is rated IP65 for ingress protection. This model complies with EN 161 standards and is certified by the EU, FM, and CSA. It is certified according to SIL 3 and PL e requirements.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Compatible with mains voltages of 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available in versions equipped with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches
