Solenoid Gas Safety Valve - Class A, EN 161, 500 mbar Max

The HONEYWELL KROMSCHRODER VAS125R/LQ is a Class A solenoid gas safety valve intended for use as a shut-off valve in gas and air systems. It conforms to EN 161 standards, is configured to be closed when not energized, and is rated for operation at pressures up to 500 mbar. The unit includes a pilot lamp and adjustable flow settings, with an IP65 ingress protection rating. This model holds EU, FM, CSA certifications; suitable for applications requiring compliance with SIL 3 or PL e.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage options: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicator and visual indicator, fitted bypass or pilot gas valve, and integrated pressure switches DG../VC
