Solenoid Gas Safety Valve - VAS-VCS, 500 mbar, EN 161, IP65 Rated

The HONEYWELL KROMSCHRODER VAS780F05LWGLB/MM/PP is a Class A solenoid gas safety valve intended for use in automatic shut-off applications. It operates in accordance with EN 161 standards and is intended for use with gas and air, featuring a maximum operating pressure of 500 mbar. When de-energized, the valve is in a closed position and includes both a pilot lamp and flow adjustment capabilities. It holds EU certification as well as FM and CSA approvals, suitable for integration into systems with requirements up to SIL 3 and PL e.

Key features:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Protection rating: IP65
• Available versions include models with position indicators, visual indicators, fitted bypass/pilot gas valves, or integrated pressure switches
