Solenoid Gas Safety Valve – VAS-VCS, 500 mbar, IP65, Class A, DN10-125

The HONEYWELL KROMSCHRODER VAS2T-/25N/LQSL is a Class A solenoid gas safety valve intended for use as an automatic shut-off component in gas and air systems. The valve remains closed when de-energized and operates at a maximum pressure of 500 mbar. It features an integrated pilot lamp, flow adjustment capability, and has an ingress protection rating of IP65. This model is EU certified, FM and CSA approved, and compatible with applications requiring compliance up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation modes: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches DG../VC
