Solenoid Gas Safety Valve - VAS-VCS, 500 mbar, IP65, Class A

The HONEYWELL KROMSCHRODER VAS3T50/-N/NKGR is a Class A solenoid gas safety valve intended for use as an automatic shut-off component in gas and air systems. It operates closed when de-energized and is rated for a maximum operating pressure of 500 mbar. The unit features a pilot lamp, flow adjustment capability, and an IP65-rated enclosure. This valve is certified to EU standards, FM, CSA, SIL 3, and PL e requirements.

Key features include:

• Size range: 1 to 9
• Nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Operation types: available with quick-opening/closing or slow-opening/quick-closing operation types
• Mains voltage compatibility: compatible with mains voltages of 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available with position indicator/visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches DG../VC
