Solenoid Gas Safety Valve – VAS-VCS, Class A, 500 mbar, IP65 Rated

The HONEYWELL KROMSCHRODER VAS125/-R/NW is a Class A solenoid gas safety valve. It is intended for use as an automatic shut-off valve in gas and air systems. The valve is configured to be closed when not energized and includes a pilot lamp indicator and adjustable flow settings. It operates at a maximum pressure of 500 mbar, meets EN 161 standards, and holds EU certification as well as FM and CSA approvals. The unit is rated IP65 for ingress protection and is certified for use in systems up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9; nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Opening/closing types: quick opening with quick closing or slow opening with quick closing
• Mains voltage options: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicator, visual indicator, fitted bypass/pilot gas valve, or integrated pressure switches
