Solenoid Gas Safety Valve – VAS-VCS, Class A, IP65, 500 mbar Max

The HONEYWELL KROMSCHRODER VAS1T10/-N/LQSL is a Class A solenoid gas safety valve. It is intended for use as an automatic shut-off component in gas and air systems. It operates with a closed position when de-energized. The unit features a pilot lamp, flow adjustment capability, and an IP65-rated enclosure. This valve meets EN 161 standards and holds EU certification as well as FM and CSA approvals. It is rated for a maximum operating pressure of 500 mbar and holds certification according to SIL 3 and PL e standards.

Key features include:

• Size range: 1 to 9; nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Opening/closing types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicator, visual indicator, fitted bypass/pilot gas valve, or integrated pressure switches
