Solenoid Gas Safety Valve – VAS-VCS Series, 500 mbar, IP65, Class A

The HONEYWELL KROMSCHRODER VAS120/-R/NWGL is a Class A solenoid gas safety valve intended for use as an automatic shut-off component in gas and air systems. The valve remains closed when de-energized and is rated for a maximum operating pressure of 500 mbar. It is equipped with a pilot lamp, adjustable flow feature, and IP65-rated enclosure. This model holds certifications under applicable EU standards, FM, and CSA approvals, with compatibility for systems requiring up to SIL 3 or PL e.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: available with quick opening/closing or slow opening/quick closing operation types
• Mains voltage compatibility: compatible with mains voltages of 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions may include models equipped with position indicators, visual indicators, fitted bypass/pilot gas valves, or integrated pressure switches
