Solenoid Gas Safety Valve - VAS115, 500 mbar, IP65, Class A Certified

The HONEYWELL KROMSCHRODER VAS115/-R/LW is a Class A solenoid gas safety valve intended for use as an automatic shut-off component in gas and air systems, according to manufacturer specifications. It operates with a closed position when de-energized and is rated for a maximum operating pressure of 500 mbar. The unit features a pilot lamp, flow adjustment capability, and an IP65-rated enclosure. It holds EU certification as well as FM and CSA approvals, and is certified for use in systems rated up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9; nominal diameter (DN) from 10 to 125
• Connection options: threaded or flanged
• Operation modes: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches
