Solenoid Gas Safety Valve - VAS125, Class A, 500 mbar, IP65 Rated

The HONEYWELL KROMSCHRODER VAS125/-R/NWSL is a Class A solenoid gas safety valve intended for use in automatic shut-off applications. It operates in accordance with EN 161 standards and is intended for use with gas and air at pressures up to 500 mbar. The valve remains closed when de-energized, features a pilot lamp, flow adjustment capability, and has an ingress protection rating of IP65. This model holds EU certification as well as FM and CSA approvals, and it holds certification according to SIL 3 and PL e standards.

Key features include:

• Size range: 1 to 9; nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicators (visual), fitted bypass or pilot gas valves, and integrated pressure switches DG../VC
