Solenoid Gas Safety Valve – VCS8100F05NLWGRB, 500 mbar, IP65 Rated

The HONEYWELL KROMSCHRODER VCS8100F05NLWGRB/MMPM/PPPP is a Class A solenoid gas safety valve intended for use in applications requiring the shut-off of gas and air. When de-energized, the valve is in a closed position and operates at a maximum pressure of 500 mbar. It includes an integrated pilot lamp and adjustable flow settings, and is rated to IP65 for ingress protection. This model is certified according to applicable EU, FM, and CSA standards, with compatibility for systems that require SIL 3 or PL e.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches DG../VC
