Solenoid Valve - Class A, 500 mbar, IP65, Flow Control

The HONEYWELL KROMSCHRODER VAS1T25/-N/NQ is a Class A solenoid valve intended for use in applications requiring the control of gas and air flow. This valve operates in a normally closed position when de-energized and is rated for operation at pressures up to 500 mbar. It includes pilot lamp, flow adjustment capability, and an IP65-rated enclosure. Certified according to applicable EU standards, FM approval, and CSA approval, it is certified for application in systems requiring SIL 3 or PL e.

Key features include:

• Size range: 1 to 9
• Nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage options: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal strip
• Available versions include models with position indicators, visual indicators, fitted bypass/pilot gas valves, or fitted pressure switches
