Solenoid Valve for Gas, 500 mbar, IP65, Class A, VCS665F05NLWR3B

The HONEYWELL KROMSCHRODER VCS665F05NLWR3B/MM1-/MMMM is a Class A solenoid valve intended for use in applications requiring automatic shut-off. The valve remains closed when de-energized and is rated for operation up to a maximum pressure of 500 mbar. It includes an integrated pilot lamp and adjustable flow settings, and has an ingress protection rating of IP65. This model is certified according to EU, FM, and CSA standards, with compatibility for systems requiring SIL 3 or PL e.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches
