Solenoid Valve for Gas, 500 mbar, IP65, EN 161 Certified

The HONEYWELL KROMSCHRODER VAS240F/NQGL is a Class A solenoid valve intended for use in applications requiring automatic shut-off of gas and air. It meets the requirements specified by EN 161 standards and is closed when not energized. The unit is rated for a maximum operating pressure of 500 mbar and includes pilot lamp indication and flow adjustment mechanisms. This model carries EU certification as well as FM and CSA approvals, and it is certified for use in systems up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9
• Nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Opening/closing modes: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Protection rating: IP65
