Solenoid Valve for Gas, Auto Shut-Off, 500 mbar, IP65, Class A

The HONEYWELL KROMSCHRODER VCS7T80A05NLQSRB/3-P3/PPPP is a Class A solenoid valve intended for use in applications requiring automatic shut-off of gas and air, conforming to EN 161 standards. The valve is configured to be in a closed position when not energized and features a pilot lamp and flow adjustment capability. It is rated for operation at maximum pressures up to 500 mbar, IP65 ingress protection, and holds EU certification as well as FM and CSA approvals. The unit is certified for systems requiring SIL 3 and PL e ratings.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Rated for operation at mains voltages of 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicator, visual indicator, fitted bypass/pilot gas valves, or integrated pressure switches
