Solenoid Valve for Gas, Auto Shut-Off, 500 mbar, IP65, VAS Series

The HONEYWELL KROMSCHRODER VAS780F05NKGRE/MM/MM is a Class A solenoid valve intended for use in applications requiring automatic shut-off of gas and air. The valve is configured to be in a closed position when not energized and is suitable for use in systems with a maximum operating pressure of 500 mbar. It features an integrated pilot lamp, flow adjustment capability, and meets IP65 ingress protection standards. The unit holds EU certification as well as FM and CSA approvals, certified according to SIL 3 and PL e standards.

Key features include:

• Valve sizes available from 1 to 9; nominal diameters (DN) from 10 to 125
• Connection options: threaded or flanged
• Quick opening/closing or slow opening/quick closing operation types
• Compatible with mains voltages: 24 V DC, 120 V AC, or 230 V AC
• Terminal-style electrical connection
• Available versions include models with position indicators, visual indicators, fitted bypass/pilot gas valves, or fitted pressure switches
