Solenoid Valve for Gas, Class A, 500 mbar, IP65, EN 161 Certified
Mfr # KS88205047
Zoro # G515424077
Specifications
Product Information
Description
The HONEYWELL KROMSCHRODER VAS8T100A05LQGLB/PP/MM is a Class A solenoid valve intended for use in applications requiring automatic shut-off of gas and air. This valve meets the requirements specified by EN 161 standards, is configured to be closed when not energized, and has a maximum rated operating pressure of 500 mbar. It features a pilot lamp for status indication and includes adjustable flow settings as per manufacturer specifications. The unit is rated IP65 for ingress protection and holds EU certification as well as FM and CSA approvals. It is also certified for use in systems up to SIL 3 and PL e.
Key features include:
- Size range: 1 to 9; nominal diameter (DN): 10 to 125
- Connection options: threaded or flanged
- Operation types: quick opening/quick closing or slow opening/quick closing
- Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
- Electrical connection via terminal block
- Available versions include models with position indicator, visual indicator, fitted bypass/pilot gas valve, or integrated pressure switches
