Solenoid Valve for Gas, Class A, 500 mbar, IP65, EN 161

The HONEYWELL KROMSCHRODER VAS240/-R/NW is a Class A solenoid valve intended for use in applications requiring automatic shut-off of gas and air, conforming to EN 161 standards. The valve is configured to be in a closed position when not energized and features both a pilot lamp and flow adjustment capabilities. It is certified for use in systems up to SIL 3 and PL e, with approvals from FM and CSA, as well as EU certification. The valve has an ingress protection rating of IP65.

Key features include:

• Maximum operating pressure: 500 mbar
• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection types: threaded or flanged
• Operation modes: quick opening/quick closing or slow opening/quick closing
• Mains voltage options: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicators, visual indicators, fitted bypass/pilot gas valves, or integrated pressure switches
