Solenoid Valve for Gas, Class A, 500 mbar, IP65, EN 161

The HONEYWELL KROMSCHRODER VAS1-0/15R/NWGR is a Class A solenoid valve intended for use in applications requiring the shut-off of gas and air. It conforms to EN 161 standards, is normally closed (de-energized state), and is rated for operation at pressures up to 500 mbar. This model includes a pilot lamp and adjustable flow settings, along with an IP65-rated enclosure. The valve holds EU certification as well as FM and CSA approvals, supporting systems rated up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicators (visual), fitted bypass/pilot gas valves, or integrated pressure switches
